SR-EOV24 Series Vertical Energy Storage System

Score

Sold: 0 Question And Answer 0

MOQ: 20 PCS

Note: If you have any questions,please contact us

1. Vertical industry integration ensures more than 5000 cycles with 80% DoD.
2. Integrated inverter design, easy to use and quick to install. Small size, minimizing installation time and cost Compact and stylish design
3.The inverter has a variety of working modes.
4. A variety of charging methods, which can be charged with photovoltaic or commercial power, or both at the same time Scalability
5.You can use 4 batteries in parallel at the same time, and can provide a maximum of 20kwh for your use.

SR-EOV24-5.0S-S1
SR-EOV24-10.0S-S1
SR-EOV24-5.0U-S1
SR-EOV24-10.0U-S1

More Products Share Factory

Consult Immediately Batch Inquiry

SRNE Solar Co.,Ltd

Since:

2009

	SR-EOV24-5.0S-S1	SR-EOV24-10.0S-S1	SR-EOV24-5.0U-S1	SR-EOV24-10.0U-S1
BATTERY TECHNICAL SPEOHCATION
Battery model	SR-EOV24-5.0A-E1
Number of batteries	1	2	1	2
Battery Energy	5.12kWh	ltt24kWh	5.12kWh	1024kWh
Battery Capacity	200AH	400AH	200AH	400AH
Weight	100kg	170kg	100 kg	170 kg
Dimension L x D x H	1190x600x184mm	1800x600x184mm	1190x600x184mm	1800x600x184mm
Battery Type	LiFePO4
Battery Rated Voltage	25.6 V
Battery Rated Voltage Range	224 ~ 28SV
Maximum Charging Current	150A
Maximum Discharging Current	150A
DOD	80%
Designed Life-span	5000
INVERTER TECHNICAL SPEQFICA7ION
INVERTER MODEL	SR-EOV24-3.5S-C1		SR-EW24-3.5U-C1
PV CHARGE
Solar Charge Type	MPPT
Maximum Output Power	4000W
PV Charging Current Range	0—80A
PV Operating Voltage Range	120 〜500V
MPPT \bltage Range	120T50V
AC CHARGE
Maximum Charge Power	2240W			1120W
AC Charging Current Range	0〜80A			O-40A
Rated Input Voltage	220/230Vac			110/120Vac
Input Voltage Range	90 〜280Vac			90 〜1404c
AC OUTPUT
Rated Output Current	3500W
Maximum Output Current	30A			40A
Frequency	50Hz			60Hz
Offload Current	35A			4 SA
BATTERY INVERTER
OUTPUT Rated Output Power	3500W
Maximum Peak Power	6000VA
Power Factor	1
Rated Output Voltage (Vac)	230Vac		120Vac
Frequency	50Hz		60Hz
Auto Switch Period	<15ms
THD	＜3%
GENERAL DATA
Communication	RS485/CAN/WIFI
Storage time / temperature	6 months @25℃;3 months @35℃;1 months @45℃;
Charging temperature range	0〜45℃
Discharging temperature range	-10〜45℃
Operation Humidity	5% 〜 85%
Nominal Operation Altitude	＜2000m
Cooling Mode	Force-Air Cooling
Noise	60dB(A)
Ingress Protection Rating	IP20
Recommended Operation Environment	Indoor
Installation Method	Vertical
Certification	UN38.3,MSDS,EN55032,EN55024,EN61000-3-2,EN61000-3-3
