HFP48V  Parallel Connection Series All-in-one Solar Charge Inverter
HFP48V  Parallel Connection Series All-in-one Solar Charge Inverter
HFP48V  Parallel Connection Series All-in-one Solar Charge Inverter

HFP48V Parallel Connection Series All-in-one Solar Charge Inverter

Score
Sold: 0 Question And Answer 0

MOQ: 20 PCS

Note: If you have any questions,please contact us

  • 1.Max.Voc:145V;Rated input voltage:220/230V or 110/120V
  • 2.High energy efficiency: up to 99.9% MPPT capture efficiency
  • 3.Efficient heat dissipation: via intelligent adjustable speed fans
  • 4.Instant viewing of operation: the LCD panel displays data and settings ,while you can also be viewed using the app and webpage
  • 5.Under-voltage and over-voltage protection and reverse polarity protection.
  • HFP4835U80-145
  • HFP4850S80-145
SRNE Solar Co.,Ltd

SRNE Solar Co.,Ltd

Since:

2009

You May Also Like

Product Description

Product characteristics

HFP48V parallel connection Series All-in-one Solar Charge Inverter
HFP48V parallel connection Series All-in-one Solar Charge Inverter



Parameters





ModelHFP4850S80-145HFP4835U80-145Adjustable
Battery Input
Battery typeSealed、FLood、GEL、LFP、TernaryV
Rated Battery Input Voltage48V ( Minimum Startup Voltage 44V)
Hybrid Charging Maxi mum Charging Current140A12 0AV
Battery Voltage Range40Vdc~60Vdc ± 0.6Vdc(Undervoltage Warning/Shutdown Voltage/OvervoItage Warning/Overvoltage Recovery...)V
Solar Input
Maximum PV Open-circuit Voltage145vdc
PV Working Voltage Range60-145Vdc
MPPT Voltage Range60-115Vdc
Maximum PV Input Current50A
Maximum PV Input Power4400W
Maximum PV Charging Current80AV
AC Input (generator/grid)
Mains Maximum Charging Current60A40AV
Rated Input Voltage220/230Vac110/120Vac
Input Voltage RangeUPS Mains Mode: (170Vac-280Vac)±2% A PL Generator Mode: (90Vac~280Vac)±2%(90Vac-140Vac)±2%V
Frequency50Hz/ 60Hz (Automatic Detection)
Mains Charging Efficiency>95%
Switch Time (bypass and inverter10ms(Typical Value)
Maximum Bypass Overload Current40A
AC Output
Output Voltage WaveformPure Sine Wave
Rated Output Voltage (Vac)230Vac (200/208/220/240Vac)120Vac (100/105/110Vac)V
Rated Output Power (VA)5000 ( 4350/4500/4750/5000)3500 (2900/3050/3200)
Rated Output Power(W)5000 ( 4350/4500/4750/5000)3500 (2900/3050/3200)
Peak Power10000VA6000VA
On-load Motor Capacity4HP2HP
Output Frequency Range(Hz)50Hz±0.3Hz/60Hz±0.3HzV
Maximum Efficiency>92%                             >91%
No-load LossNon Energy-saving Mode: <50W Energy-saving Mode : <25W (Manual Setup )
General
Number of parallel/split phases1-6PCS
CertificateCEflEC 62109-1)CEQEC 62109-1)/ CETL(UL 1741/ CSA C22.2 NO.107.1)
EMC Certification LevelEN 61000, C2
Working Temperature Range-15°C ~ 55°C
Storage Temperature Range-25°C ~ 60°C
Humidity Range5% to 95%(Conformal Coating Protection)
Dimensions426mm*322mm*124mm
Weight (KG)10.8



 Product introduction:
·Load friendly: Stable sine wave AC output via SPWM modulation
·Supports a wide range of battery technology: GEL, AGM, Flooded, LFP, and program.
·Dual LFP battery activation method: PV&mains
·Uninterrupted power supply: simultaneous connection to utility grid/generator and PV
·Intelligent programming: the priority of the output from different energy sources can be set
·High energy efficiency: up to 99.9% MPPT capture efficiency
·Instant viewing of operation: the LCD panel displays data and settings ,while you can also be viewed using the app and webpage
·Power saving: power saving mode automatically reduces power consumption at zero-load
·Efficient heat dissipation: via intelligent adjustable speed fans
·Multiple safety protection functions: short circuit protection, overload protection, reverse orality protection, and so on.
under-voltage and over-voltage protection and reverse polarity protection.
·Supports up to 6 devices of the same model connected in parallel (forming a single-phase,split-phase,three-phase electrical system)
