Quantitative Real-time PCR System ZIP-96V
MOQ: 1 Set
Note: If you have any questions,please contact us
- 1. User-friendly for first-time and experienced operators
- 2. No ROX correction required preset projects, such as COVID-19, influenza A/B project
- 3. Excellent optical system,use high efficiency LEDs light source, maintenance-free for life
- 4. Unique test tube side day lighting technology, four-channel fast day lighting only takes 20s, automatically adjusts gain, improves the fluorescence signal sensitivity and signal to noise ratio
- 5. Unique time-resolved signal separation technology, no multi-color crosstalk
- ZIP-96V
Zybio Inc
Since:
2008
Product Description
Quantitative real-time PCR system ZIP-96V is 96-well real-time PCR instrument based on fresnel lens optical signal acquisition technology, time-resolved signal separation technology and unique temperature control technology
Advanced temperature control block
The high-level Peltier chip combined with a new generation of semiconductor heating and cooling technology greatly improves the heating and cooling rate, and the heating rate can reach up to 6°C/s
Six independent temperature control blocks improve the accuracy and uniformity of temperature control
Technical parameters
| Basic parameters | |
| Model | ZIP-96V |
| Dimensions (W×D×H, mm) | 425*320*205 |
| Weight | 13.5Kg |
| Throughput | Up to 96 tests per run |
| Reaction volume | 20-100μL |
| Sample Format | 0.2ml PCR tube/ |
| 8-strip PCR tube/ | |
| 96-well plate | |
| Supported dye | Channel 1: FAM |
| Channel 2: VIC, HEX | |
| Channel 3: ROX | |
| Channel 4: CY5 | |
| Fluorescent channels | 4 detection channels |
Optical system
| Excitation light source | High efficiency LEDs |
| Detector | Photo diode |
| Excitation wavelength | 460nm~480nm,525nm~545nm, 575nm~595nm,600nm~620nm |
| Emission wavelength | 505nm~525nm,555nm~575nm, 600nm~620nm,660nm~680nm |
| Fluorescence repeatability | < 2% |
| Fluorescence linear | r > 0.99 |
Software
| Applications | Qualitative/ Absolute Quantification Analysis |
| Scan mode | All-channel scanning |
| Data export | Excel |
| Report | Multiple printing templates/ customized template |
Thermal cycle technology
| Temperature control | Peltier |
| Temperature control block | 6 blocks |
| Temperature range | 4~99°C |
| Heating rate | > 2.5°C/s |
| Cooling rate | > 2.0°C/s |
| Temperature fluctuation | ± 1°C |
| Temperature accuracy | ≤ ±0.5°C |
| Hot-lid temperature range | 30~110°C |
Working Environment
| Power supply | 100-240 V AC,50-60 Hz |
| Operating system | Windows 7/10 |
| Interface | USB |
| Working Temperature | 10-30°C |
| Working Humidity | 20-85 % |
