454E Type Tractor Combine New Technology And New Structure Together
MOQ: 100 PCS
Note: If you have any questions,please contact us
- 1.The engine is Direct drive
- 2.Two/four wheel drive
- 3.Perfect in performance of Hydraulic suspension system
- 4.Single - side braking system and standard single/double speed power output
- 5.There are both Mechanical or hydraulic steering system
- 454E
Jiangsu Yueda Investment Co., Ltd
Since:
1985
Product Description
Jinma 40-80 type tractor is designed base on Jinma 40-65HP Series tractor, it combine new technology and new structure together. It has the advantages of suitable power, large traction, compact structure, high transmission efficiency, easy to operate, easy to maintain, convenient to match, economical to use and good comprehensive utilization performance
| Model | 454E | |
| Drive Type | 4WD | |
| Overall Dimensions L×W×H(mm): | 3375×1585×2510 | |
| Wheel Track (mm) | Front | 1050 |
| Rear | 1240 | |
| Wheel Base(mm) | 1835 | |
| Ground Clearance (mm) | 320 | |
| Rated Traction Force(N) | 7500 | |
| Construction Mass(kg) | 1587 | |
| Min.Turning Radius(m) | 3.5 | |
| Theoretical Speed (km/h) | Forward | 1.86/2.84/4.45/6.14/8.61/13.12/20.58/28.37 |
| Reverse | 2.45/11.84 | |
| Theoretical Speed | Forward | 0.35/0.53/0.83/1.14/1.61/2.45/3.84/5.29 |
| (With creeper) km/h) | Reverse | 0.46/2.21 |
| Theoretical Speed | Forward | 1.86/2.84/4.45/6.14/8.61/13.12/20.58/28.37 |
| (With Shuttle) km/h) | Reverse | 1.79/2.73/4.29/5.91/8.29/12.64/19.83/27.33 |
| Model | 4L45B | |
| Type | In-line ,water cooled,4 stroke cycle | |
| Rated Power(kw/hp) | 33.1 | |
| Rated Speed (rpm) | 2400 | |
| Bore×Stroke (mm) | 95*100 | |
| Total Displacement(L) | 2.83 | |
| Clutch | 10 inch dual clutch | |
| Gear Box | (4+1)*2 | |
| Main Drive | Two bevel gears | |
| Differential | Two planetary gear | |
| Differential Lock | Jaw lock | |
| Final Transmission | Single spur gear | |
| Tyre | Front | 6.50-16 |
| Rear | 11.2-24 | |
| Steering Gear | Hydraulic steering | |
| Brake | Disc brake | |
| Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (N) | 7.5 |
| 3-Point Suspension | Category :I | |
| P.T.O Shaft | Rotating Speed (rpm) | 540/1000 |
| Spline Size | 34.79 | |
