JM504D Jinma Tractor Is Design For Greenhouse Planting
MOQ: 1 PCS
Note: If you have any questions,please contact us
- 1.The engine is Direct drive
- 2.Two/four wheel drive, 8 gear transmission
- 3.Perfect in performance of Hydraulic suspension system
- 4.Single - side braking system and standard single/double speed power output
- 5.There are both Mechanical or hydraulic steering system
- JM504D
Jiangsu Yueda Investment Co., Ltd
Since:
1985
Product Description
Tractor | Model | JM504D | |
| Drive Type | 4WD | ||
| Overall Dimensions L×W×H(mm): | 3249x1296x1300 | ||
| Wheel Track (mm) | Front | 990 | |
| Rear | 1040 | ||
| Wheel Bass(mm) | 1954 | ||
| Ground Clearance (mm) | 250 | ||
| Rated Traction Force(N) | 9800 | ||
| Construction Mass(kg) | 1630 | ||
| Min.Turning Radius(m) | |||
| Theoretical Speed (km/h) | Forward | 1.60，2.01，3.28，5.20，6.79，8.57，13.96，22.13 | |
| Reverse | 1.49，6.34 | ||
Engine | Model | JD4E6 | |
| Type | 4-cylinder, Vertical,water cooled, 4 stroke cycle | ||
| Rated Power(kw/hp) | 36.77/50 | ||
| Rated Speed (rpm) | 2300 | ||
| Bore×Stroke (mm) | 100×112 | ||
| Total Displacement(L) | 3.519 | ||
Drive | Clutch | 10" Single-Stage | |
| Gear Box | (4+1)×2 | ||
| Main Drive | One Pair of Spiral Bevel Gearing | ||
| Differential | Bevel Gear | ||
| Differential Lock | Jaw Lock | ||
| Final Transmission | Spur Gear,External,Gearing | ||
Traveling | Type | Front | 6.00-12 |
| Rear | 9.5-20 | ||
| Steering Gear | Full Hydraulic Steering | ||
| Brake | Disc type | ||
Working | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (N) | 6600 |
| 3-Point Suspension | Category:I | ||
| P.T.O Shaft | Rotating Speed (rpm) | 540/720 or540/1000 | |
| Spline Size | 6-Φ35Rectangular Spline | ||
