Euro III MD554 Series Tractor Adopts A Straight Barrel Shape And Compact
Euro III MD554 Series Tractor Adopts A Straight Barrel Shape And Compact
Euro III MD554 Series Tractor Adopts A Straight Barrel Shape And Compact
Euro III MD554 Series Tractor Adopts A Straight Barrel Shape And Compact

Euro III MD554 Series Tractor Adopts A Straight Barrel Shape And Compact

Score
Sold: 0 Question And Answer 0

MOQ: 1 PCS

Note: If you have any questions,please contact us

  • 1. Equipped with synchronization shift gearbox
  • 2. Developed with AVL company, the tractor can
  • 3.Stable and reliable four-wheel drive clutch ensures traffic-ability on complex fields.
  • 4. The innovative shift synchronizer makes shifting light and convenient;
  • 5. 16 + 8 (optional creeper gear 24+12), multi-level gear, wide speed range, the tractor can meet the demands of both the low-speed farmland operation and the high-speed road transportation;
  • Euro III MD554
Shandong Wuzheng Group Co. Ltd

Shandong Wuzheng Group Co. Ltd

Since:

1961

You May Also Like

Product Description

1. Chassis structure adopts a straight barrel shape and compact, strong and reliable structure. The chasis adopts synchronizer shift technology, shift is convenient and comfortable; The gear type is 16F+8R with different speed to choose (1.84~38.26km/h). Creeper gear is available and gear can be up to 24F+12R, and minimum velocity is 0.27km/h.

2. Synchronous power output can meet the precise operation demand;

3. Active pressure lubrication prolongs the service life of key parts, and reduces maintenance costs.

4. The advantages of compact structure, short wheelbase, small turning radius and flexible steering make the tractor more suitable for the operation on small plot.



ModelMD554
Dimension (L×W×H)mm3850×1905×2580  With cab);3850×1905×2600( With ROPS)
Min. operating weightkg2700
Wheel track (front/rear) 1295/1280、1380、1400
Wheelbasemm2060
Min. ground clearancemm375
Minimum turning radiusm4.5±0.5







Engine

Model/4G33TC
Type/In-line, water-cooling, four stroke, DI



Qty of cylinders

/4
Rated powerr/min2400
Rated speedKw40.5





Drive train

Clutch/Dry, independent control, dual stage
Gearbox/

16+8,(2+1)×4×2/

24+12,(2+1)×4×3

Gear shift type/Sychronizer shift
Steering  typeSteering type/Hydraulic steering
BrakeBrake type/Service Brake: mechnical control, wet, disc  Parking brake: locked pedal
Walking deviceTire size (front/rear)/9.50-20、8.3-24/13.6-28、12.4-32、14.9-30



Working device

Suspension device type/Postposition three-point suspension
Suspension device category/Category I
Tillage Depth Adjustment/Comprehensive adjustment
Hydraulic output device Multi-way valve output
Standard PTO speedr/min540/1000;540/750
