ME Series Tractor Is A Series Of Multi-functional Tractor With Excellent Quality
MOQ: 1 PCS
Note: If you have any questions,please contact us
- 1. Renoman adopts reasonable man-machine engineering operation interface, which makes the operation more smooth and convenient;
- 2.The data is clear and easy to read on clear and concise dashboard;
- 3.Meticulous and thoughtful protection device.
- 4.Excellent ergonomic engineering and clear design bring you unprecedented ride comfort
- 5.Enough power, large torque and low fuel consumption of TS tractor brings stronger power and higher efficiency;
- Euro II ME804
Shandong Wuzheng Group Co. Ltd
Since:
1961
Product Description
1. ME Series tractor is a series of multifunctional tractor with excellent quality. Products adopt humanized design and outstanding production technology. The user will experience many advantages beyond imagination, high efficiency operation, pleasure of driving, and greater economic benefits.
2. Key parts of the bearing and sealing element are imported from abroad so as to ensure the stability and reliability of the product. Lower cost of using brings higher returns;
| Model | ME804 | ||
| Dimensions (L × W × H) | mm | 4295×2050×2770 | |
| Min. operating weight (kg) | kg | 3800 | |
| Wheelbase | mm | 2180 | |
Wheel track (front/rear) | mm | 1610/1605 | |
| Minimum ground clearance | mm | 390 | |
| Minimum turning radius | m | 4.2 | |
Engine | Model | / | YC4B90Z-T20 |
| Type | / | Inline, direct injection, water cooling, four stroke | |
| Qty of cylinders | Cylinder | 4 | |
| Rated power | KW | 59 | |
| Rated speed | r/min | 2300 | |
| Steering | Steering type | / | Hydraulic steering |
Brake | Brake type | / | Pedal,mechanical transmission,hydrostatic, disc type |
Drive train | Clutch type | / | single disc, dry, independent manipulation |
| Gearbox type | / | 4×(2+1)×2 | |
| Gear shift type | / | Meshing gear shift | |
| Walking device | Tire size(front/rear) | / | 11.2-24/16.9-34 |
Working device | Suspension device type | / | Rear, three-point suspension |
| Suspension device category | / | Category Ⅱ | |
| Tillage Depth Adjustment |
/ | Force and position comprehensive adjustment; position adjustment, floating adjustment | |
| Hydraulic output device | / | Multi-way valve output | |
| Standard PTO speed | r/min | 540/1000 | |
